NSP-5 Tactical Multi-INT Radar NSP-5 Tactical Multi-INT Radar Delivering real-time, actionable intelligencein day, night and all-weather conditions Enabling multi-INT, all-weather ISR capabilities normally found on larger, more expensive platforms. SAR/MTI/CCD Radar Data Advanced, low-SWaP, multi-mode radar in a protected weatherized pod. Coherent Change Detection CCD helps discover surface disturbances more effectively than EO or IR alone. Wide-area search modes Ideal for maritime patrol, force protection and counter-trafficking missions. Get the full specs and details. DOWNLOAD PRODUCT CARD Specifications Operational Ranges Operating Frequency: Ku band Operating Altitude: Mode dependent up to 10,000 ft AGL SAR imaging range: 24 km (at 1m resolution) MTI (vehicle): 12 km max. range; max. continuous coverage 60 km2 Standard Data Formats KML, Complex NITF JPG, PNG, BMP STANAG 4607 Detects, STANAG 4676 Tracks Variants NSP-5(X): SAR, CCD, GMTI/MMTI (advanced), DMTI NSP-5(S): SAR, GMTI/MMTI (standard) X variant available to approved customers Operating Software Uses “Lisa 3D” intuitive software for Command and Control (C2) and Processing, Exploitation, and Dissemination (PED) Pre-mission flight geometry based on data collection plan Operational capability to program the radar, dynamically change plans and modes, and perform real-time analysis Post-mission analysis with export to standard formats and data forensics All-weather, high-quality, multi-mode radar • Synthetic Aperture Radar (SAR) • Moving Target Indicator (MTI) • Coherent Change Detection (CCD) Multiple radar search modes • Stripmap – Monitors a swath of ground parallel to the direction of flight. • Spot light – Monitors a selected area of ground while UAS flies past or around it. • Wide Area – Monitors the large area within the radar’s FoV for potential targets of interest. Wide-area search modes • Ground Moving Target Indicator (GMTI) • Dismount Moving Target Indicator (DMTI) • Maritime Moving Target Indicator (MMTI) • High Value Target (HVT) mode Developed and produced by IMSAR. Integrated and tested in collaboration between Insitu and IMSAR. Ready to learn more? CONTACT OUR TEAM Related Systems NSP-5 works in conjunction with these Insitu systems. RQ-21A Increasing expeditionary capabilities with more payload options Learn More In the News Related Stories QE-1 Squadron Completes 1 Year of Service Brazilian QE-1 ScanEagle Squadron Harpia celebrated the completion of 1 year of service… Read More » Insitu Announces its High Seas, Long Endurance Integrator VTOL Uncrewed Aircraft System at Navy League’s Sea-Air-Space Global Maritime Expo Integrator VTOL launches vertically on ships or land without sacrificing payload capacity or endurance. Read More » Insitu Sets Company Record for Longest Flight at 25.5 hours with its Integrator Uncrewed Aircraft System Insitu, A Boeing Company, recently set a company record for the longest duration flight with a 25.5-hour sortie with its Integrator Uncrewed Aircraft System (UAS) on an operational mission. Read More »
