WAMI WAMI Wide-Area Motion Imagery (WAMI) for Integrator RedKite® Block II is a small electro-optical system capable of monitoring a city-sized area in real time.BlackKite® takes your city-wide search from day to night using Mid-Wave Infrared (MWIR). Enables wide-area monitoring Monitors 10 mi² (16 km²) area within line-of-sight range of the GCS Onboard data storage RedKite offers up to 8 hours of mission data (11 hours for BlackKite) onboard vehicle supporting real-time or historical data Real-time alerts User-defined “watchboxes” provide sensor operators with automated alerts when items of interest move in/out for real-time tracking Get the full specs and details. DOWNLOAD REDKITE PRODUCT CARD DOWNLOAD BLACKKITE PRODUCT CARD RedKite Specifications Operational altitude: 5,000-15,000 ft / 1,500-4,500 m AGL Area of coverage at 5000 ft / 1,500m AGL: 1.3 NM² / 4.5 km² (2.4 km diameter) Area of coverage at 12,000 ft / 4000m AGL: 5 NM² / 16 km² (4.5 km diameter) GSD at 12,000 ft / 4,000 m AGL: 12 inches / .3 m Camera: Monochrome CMOS (250 megapixel) Refresh rate: 1 Hz Cross-cueing: Yes Viewer windows: Up to 10 unique streaming video windows GCS archive length: 100 hrs, expandable Onboard archive length: >4 hrs, expandable to 8 hrs Transmission to mobile devices: Yes Compact embedded processing: includes north-up rendering, real-time and DVR streaming, and full-mission storage Data link: Internal data link, providing a fully integrated, single LRU BlackKite Specifications Operational altitude: 5,000-15,000 ft / 1,500-4,500 m AGL Area of coverage at 5000 ft / 1,500m AGL: .5 NM² / 1.7 km² (1.5 km diameter) Area of coverage at 12,000 ft / 4000m AGL: 3.5 NM² / 12 km² (4 km diameter) Ground Sample Distance (GSD) at 5,000 ft / 1,500 m AGL: 8.5 inches / .22 m GSD at 12,000 ft / 4,000 m AGL: 23 inches / .6 m Camera: 3 Mpx Refresh rate: 1 Hz Cross-cueing: Yes Viewer windows: Multiple unique streaming video windows GCS/SCS archive length: 160 hrs, expandable Onboard archive length: 5 hrs (4 TB drive), ~11 hrs (8 TB drive) Transmission to mobile devices: Yes Compact embedded processing: North-up rendering, real-time and DVR streaming, and full-mission storage Internal Data link: Fully integrated, single Line Replaceable Unit (LRU) Cross cue Support cross-cueing to Integrator’s primary FMV turret for higher resolution interrogation of subjects of interest. Support multiple operators Support multiple sensor operators with up to 10 video streams at once, each viewing independent streams. Geospatial and temporal bookmarking allows users to mark and share locations. Automated detection alerts User-defined “watchboxes” provide sensor operators with automated alerts when items of interest move in/out for real-time tracking. Simultaneous target detection Detect, track, and label geographically dispersed still or moving targets. Forensic Analysis Operators can rewind imagery in forensic mode to trace targets to their points of origin and review events. RedKite and BlackKite are integrated and tested in collaboration between Insitu and Logos Technologies. Ready to learn more? CONTACT OUR TEAM Related Systems RedKite works in conjunction with these Insitu systems. TacitView TacitView delivers FMV media manipulation and management tools Learn More Catalina Power your media enterprise with Catalina server-side software – Insitu’s sophisticated multimedia server Learn More In the News Related Stories Insitu Pacific’s Uncrewed Next-gen Sensors Demonstrated at U.S. Army Exercise Insitu Pacific demonstrated next generation sensor capabilities and autonomous technologies in California as part of the U.S. Army’s Project Convergence 2022 late last year. Read More » Insitu Announces its High Seas, Long Endurance Integrator VTOL Uncrewed Aircraft System at Navy League’s Sea-Air-Space Global Maritime Expo Integrator VTOL launches vertically on ships or land without sacrificing payload capacity or endurance. Read More » Insitu Sets Company Record for Longest Flight at 25.5 hours with its Integrator Uncrewed Aircraft System Insitu, A Boeing Company, recently set a company record for the longest duration flight with a 25.5-hour sortie with its Integrator Uncrewed Aircraft System (UAS) on an operational mission. Read More »
